50/60HZ Soundproof Cummins Diesel Generator Set for Charging in Factory Silent type

Name: 50/60HZ Soundproof Cummins Diesel Generator Set for Charging in Factory Silent type
Brand: Changsha Mingbang Intelligent Technology Co., Ltd.
SKU: NTA855-G2A
Price: 1181600.00 USD
Availability: InStock

Brand Name:	Cummins
Model Number:	NTA855-G2A
MOQ:	1PC
Price:	Price:Negotiable
Payment Terms:	Western Union,T/T,D/P,L/C
Supply Ability:	200pcs/month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO 9001:14000,CE,EACC

Place Of Origin::

Jiangsu China

Brand Name::

MBKL

Rated Voltage::

230V/400V

Engine Model::

Cummins NTA855-G2A

Rated Current::

720A

Frequency::

50Hz/60Hz

Alternator::

MBC5B

Control Panel::

Deepsea / Harsen / Smartgen

Certificate::

ISO 9001:14000,CE

ATS::

Optional

Delivery::

7-30 Days

Warranty Time::

1 Year

Genset Dimension::

3500×1300×1800mm

Genset Weight::

3500kgs

Speed::

1500rpm/1800rpm

Model Number::

MBC5B

Packaging Details:

Plastic wrapped on wooden bearers as consumer requirements. LCL, 20FT and 40FT are available.

Supply Ability:

200pcs/month

Highlight:

345kva Dynamo Diesel Generator

275kw Dynamo Diesel Generator

345kva Diesel Generators Sets

Product Description

Power Generator Set 345kva 60HZ 345 Kva Diesel Generator Dynamo Generator Set Prime Power 275kw With Smartgen Controller

Dynamo Generator Genset Specification
Manufacturer		Changsha Mingbang Intelligent Technology Co.Ltd
Model		MB-C300
Prime Power		275KW/343.75KVA
Standby Power		300KW/375KVA
Power Factor		COSΦ=0.8(lagging)
Max. Output current		540A
Genset Weight		2800KG
Length x Width x Height (Engine) (mm)		3000×980×1670
Voltage		400/230V
Frequency		50HZ
Engine Specification
Manufacturer		Chongqing Cummins Engine Co. Ltd
Model		NTA855-G2A
Rated speed		1500rpm
Prime Power		312KW/390KVA
Standby Power		343KW/428.75KVA
Fuel Consumption		<=205g/KW.H
Lube oil capacity		39L
Bore (mm) x Stroke (mm)		140*152
Compression ratio		14.0:1
Displacement (litre)		14L
Coolant capacity, L		/
Configuration		6 in line ,four-stroke, Turbocharged, Charge Air Cooled
Cooling		Liquid Cooled
Governor type		Electronic
Starting voltage		24 Volts DC
Filtration system		Air Filter/Fuel Filter/Oil Filter
Alternator Specification
Manufacturer		Changsha Mingbang Intelligent Technology Co.Ltd
Model		MBC4E
Voltage Regulator		AVR
Voltage adjust range		±1%
Rated Voltage/Frequency/Factor		400/230V, 50HZ, COSΦ 0.8(lagging) ,Three-phase Four-wire
Steady-state Frequency		5%
No-load Voltage Adjust Range		>=95%-105%
Insulation Class		H
IP Protection		22
Excitation Type		Blushless

Rated power	Engine	Alternator	Control panel
24kw~1500kw	Cummins	Stamford Leroy somer Marathon Mecc alte ABB Chinese alternators	Deepsea ComAp Harsen Smartgen
36kw~18+00kw	Perkins
68kw~560kw	Volvo
20kw~200kw	Deutz
40kw-2200kw	Yuchai
50kw-2200kw	Weichai
540kw-1900kw	Mitsubishi
50kw-800kw	SDEC
650kw~2200kw	Chinese engine

50/60HZ Soundproof Cummins Diesel Generator Set for Charging in Factory Silent type 0

About MingBang Intelligent Technology

50/60HZ Soundproof Cummins Diesel Generator Set for Charging in Factory Silent type 3

Mingbang Intelligent Technology Co.,LTD was established in 2005,occupies an area of 5042 square meters,located in Yangzhou city,Jiangsu Province,which is the central part of manufacturing industry zone in Southeast China near Shanghai

Mingbang works closely with all large power manufactures such as Cummins, Perkins, Deutz,
Volvoand Chinese local brands SDEC,Yuchai,Jichai diesel generator sets,engines with
Stamford,Marathom,Leroy-Somer,and MBKL manufactured alternators ,and so on. Key diesel
generator stock ranges from 10KVA to 3000 KVA, classifying silent generator, open generator ,
container generator, mobile genset, and so on.

Whether you require support for an office, residential development ,industrial development or
shopping centre, hospital,railways,prison, hotal, airport ,bank data centre, Mingbang will
support you the most reliable and most cost-efficient generators and accessories.
Weclome to visit our factory!

Our customers

Our with Cummins engine NAT855-G2A Cummins 275kw diesel generator

service quality assurance:

1)Before-sale Service:

we provide detailed product technical parameters for equipment choosing and system designing

2)Service quality assurance:

our sale staffs are all experience and professional,who can provide the most proper system design and

optimized equipment for the customers.

3)After sale maintenance service:

We create files for end user and provide them follow-up service,regular return visit and permanent

maintenance.

4)Spare parts supply:

We provide all kinds of spare parts and technical support.

5)Main overhaul or maintenance service:

We provide perennial major overhaul and maintenance service.

More details for diesel generator sets ,please contact us any time
