YC4D90Z-D21 Engine 62.5kva YUCHAI Diesel Generator Set

Name: YC4D90Z-D21 Engine 62.5kva YUCHAI Diesel Generator Set
Brand: Changsha Mingbang Intelligent Technology Co., Ltd.
SKU: YC4D90Z-D21
Price: 591,700.00 USD
Availability: InStock

Brand Name:	Yuchai
Model Number:	YC4D90Z-D21
MOQ:	1PC
Price:	Price:Negotiable
Payment Terms:	Western Union, T/T, D/P, L/C
Supply Ability:	200pcs/month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO 9001:14000,CE,EACC

Brand Name::

50KW Yuchai Diesel Generator

Rated Voltage::

230V/400V

Engine Model::

Yuchai YC4D90Z-D21

Rated Current::

90A

Frequency::

50Hz/60Hz

Alternator::

MBC22C

Control Panel::

Deepsea / Harsen / Smartgen

Certificate::

ISO 9001:14000,CE

ATS::

Optional

Delivery::

7-30 Days

Warranty Time::

1 Year

Genset Dimension::

2160*780*1300mm

Genset Weight::

950kgs

Speed::

1500rpm/1800rpm

Model Number::

MB-40

Packaging Details:

Plastic wrapped on wooden bearers as consumer requirements. LCL, 20FT and 40FT are available.

Supply Ability:

200pcs/month

Highlight:

YC4D90Z-D21 YUCHAI Diesel Generator

62.5kva YUCHAI Diesel Generator Set

62.5kva 50kw Diesel Generator

Product Description

Yuchai Diesel Generator Sets Description:
50kw rainproof electric generator with YUCHAI engine YC4D90Z-D21
(1) Full control panel with power indicator light and oil light.
(2).Emergency shutdown for low oil pressure and high water temperature.
(3).Large fuel tank ensure continuous running.
(4).Low noise & vibration.
(5).Compact structure.
(6).Reliable performance.
(7).Easy for installation and maintenance.
YC4D90Z-D21 Engine 62.5kva YUCHAI Diesel Generator Set 0

Manufacturer		Changsha Mingbang Intelligent Technology Co.Ltd
Model		MB-50
Prime Powder		50KW/62.5KVA
Power Factor		COSΦ=0.8(lagging)
Max. Output current		90A
Genset Weight		950kg(Net)
Length x Width x Height (Engine) (mm)		21607801300
Voltage		400/230V
Frequency		50HZ
Yuchai Engine Specification
Manufacturer		Guangxi Yuchai Machinery Group Co., Ltd
Model		YC4D90Z-D21
Rated speed		1500rpm
Prime Powder		60KW/75KVA
Standby Powder		66KW/82.5KVA
Fuel Consumption		<=210g/KW.H
Lube oil capacity		17L
Bore (mm) x Stroke (mm)		108*115mm
Compression ratio		17.5:1
Displacement (litre)		4.214
Coolant capacity, L		/
Configuration		4 in line ,four-stroke, Turbocharged, Charge Air Cooled
Cooling		Liquid Cooled
Governor type		Electronic
Starting voltage		24 Volts DC
Filtration system		Air Filter/Fuel Filter/Oil Filter
Alternator Specification
Manufacturer		Changsha Mingbang Intelligent Technology Co.Ltd
Model		MBC22C
Voltage Regulator		AVR
Voltage adjust range		±1%
Rated Voltage/Frequency/Factor		400/230V, 50HZ, COSΦ 0.8(lagging) ,Three-phase Four-wire
Steady-state Frequency		5%
No-load Voltage Adjust Range		>=95%-105%
Insulation Class		H
IP Protection		22
Excitation Type		Blushless

YC4D90Z-D21 Engine 62.5kva YUCHAI Diesel Generator Set 1

About MingBang Intelligent Technology

YC4D90Z-D21 Engine 62.5kva YUCHAI Diesel Generator Set 3

Mingbang is the professional manufacturer of power generator, light tower and air compressor in China. We provides a complete line of generators for commercial,industrial and residential application.works closely with all large power manufactures such as Cummins, Perkins, Deutz,Volvo and Chinese local brands SDEC,Yuchai,Jichai diesel generator sets,engines with Stamford,Marathom,Leroy-Somer,and MBKL manufactured alternators ,and so on. We specialize in providing a wide range of well known and trusted brands of diesel generators, supplying generators from 4kw to 2200kw at competitive prices.
Besides generators, we also product the refer product include lighting towers and air compressor. At the same time, we also provide the reference electrical products, include ATS, Synchronization system & switch gear.

Our customers

Yuchai Diesel Generator Set Brushless Copper Generator With Automatic Voltage Regulator 50kw 62.5kva YC4D90Z-D21

Free loading capacity analysis
Free technology consulations
Free testing and debuging
12months or 1000hours warranty service
Spare parts offered
OEM service buyer label offered
24/7 on-line technical service

More details for diesel generator sets ,please contact us any time

Your further inquiry will be welcome!!
