soundproof 180KW 225KVA Silent Power Generator Yuchai Diesel Generator Sets

Name: soundproof 180KW 225KVA Silent Power Generator Yuchai Diesel Generator Sets
Brand: Changsha Mingbang Intelligent Technology Co., Ltd.
SKU: YC6A245L-D21
Price: 591,700.00 USD
Availability: InStock

Brand Name:	Yuchai
Model Number:	YC6A245L-D21
MOQ:	1PC
Price:	Price:Negotiable
Payment Terms:	Western Union,T/T,D/P,L/C
Supply Ability:	200pcs/month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO 9001:14000,CE,EACC

Brand Name::

180KW Yuchai Diesel Generator

Rated Voltage::

230V/400V

Engine Model::

Yuchai YC6A245L-D21

Rated Current::

324A

Frequency::

50Hz/60Hz

Alternator::

MBC27I

Control Panel::

Deepsea / Harsen / Smartgen

Certificate::

ISO 9001:14000,CE

ATS::

Optional

Delivery::

7-30 Days

Warranty Time::

1 Year

Genset Dimension::

2500×950×1500mm

Genset Weight::

1700kgs

Speed::

1500rpm/1800rpm

Model Number::

MB-180

Packaging Details:

Plastic wrapped on wooden bearers as consumer requirements. LCL, 20FT and 40FT are available.

Supply Ability:

200pcs/month

Highlight:

225KVA silent power generator

180KW silent power generator

180KW 225 kva diesel generator

Product Description

180kw 225kva YC6A245L-D21 Yuchai Diesel Generator Sets Description :

a. Diesel engine

b. Alternator

c. Control panel

soundproof 180KW 225KVA Silent Power Generator Yuchai Diesel Generator Sets 0

Manufacturer		Changsha Mingbang Intelligent Technology Co.Ltd
Model		MB-180
Prime Powder		180KW/225KW
Power Factor		COSΦ=0.8(lagging)
Max. Output current		324A
Genset Weight		1700kg(Net)
Length x Width x Height (Engine) (mm)		2500×950×1500
Voltage		400/230V
Frequency		50HZ
Engine Specification
Manufacturer		Guangxi Yuchai Machinery Group Co., Ltd
Model		YC6A245L-D21
Rated speed		1500rpm
Prime Powder		165KW/206.25KVA
Standby Powder		181KW/226.25KVA
Fuel Consumption		<=205g/KW.H
Lube oil capacity		24L
Bore (mm) x Stroke (mm)		108×132mm
Compression ratio		17.3:1
Displacement (litre)		7.5
Coolant capacity, L		/
Configuration		6 in line ,four-stroke, Turbocharged, Charge Air Cooled
Cooling		Liquid Cooled
Governor type		Electronic
Starting voltage		24 Volts DC
Filtration system		Air Filter/Fuel Filter/Oil Filter
Alternator Specification
Manufacturer		Changsha Mingbang Intelligent Technology Co.Ltd
Model		MBC27I
Voltage Regulator		AVR
Voltage adjust range		±1%
Rated Voltage/Frequency/Factor		400/230V, 50HZ, COSΦ 0.8(lagging) ,Three-phase Four-wire
Steady-state Frequency		5%
No-load Voltage Adjust Range		>=95%-105%
Insulation Class		H
IP Protection		22
Excitation Type		Blushless

soundproof 180KW 225KVA Silent Power Generator Yuchai Diesel Generator Sets 1

About MingBang Intelligent Technology

soundproof 180KW 225KVA Silent Power Generator Yuchai Diesel Generator Sets 3

Mingbang is the professional manufacturer of power generator, light tower and air compressor in China. We provides a complete line of generators for commercial,industrial and residential application.works closely with all large power manufactures such as Cummins, Perkins, Deutz,Volvo and Chinese local brands SDEC,Yuchai,Jichai diesel generator sets,engines with Stamford,Marathom,Leroy-Somer,and MBKL manufactured alternators ,and so on. We specialize in providing a wide range of well known and trusted brands of diesel generators, supplying generators from 4kw to 2200kw at competitive prices.
Besides generators, we also product the refer product include lighting towers and air compressor. At the same time, we also provide the reference electrical products, include ATS, Synchronization system & switch gear.

Our customers

Diesel Standby Generator Yuchai Engine Industrial Alternator 225KVA Silent Power Generator Air-Cooled Generating Set

Our factory has CCEC, DCEC, VOLVO, PERKINS,MTU,Deutz, Daewoo, SDEC, Weichai,Jichai etc. World and Chinese famous engine for generators set. We have specialized in synchronous 100%copper wire alternator for more than 20 years. Mingbang brand alternator has been expanded all over the world. The power range of our generator is from 4KW~2200KW.

More details for diesel generator sets ,please contact us any time

Your further inquiry will be welcome!!
