Yuchai Silent Diesel Generator Sets YC6MK350L-D20 200KW/250KVA for sale

Name: Yuchai Silent Diesel Generator Sets YC6MK350L-D20 200KW/250KVA for sale
Brand: Changsha Mingbang Intelligent Technology Co., Ltd.
SKU: YC6MK350L-D20
Price: 591,700.00 USD
Availability: InStock

Brand Name:	Yuchai
Model Number:	YC6MK350L-D20
MOQ:	1PC
Price:	Price: Negotiable
Payment Terms:	Western Union,T/T,D/P,L/C
Supply Ability:	200pcs/month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO 9001:14000,CE,EACC

Brand Name::

200KW Yuchai Diesel Generator

Rated Voltage::

230V/400V

Engine Model::

Yuchai YC6MK350L-D20

Rated Current::

360A

Frequency::

50Hz/60Hz

Alternator::

MBC27J

Control Panel::

Deepsea / Harsen / Smartgen

Certificate::

ISO 9001:14000,CE

ATS::

Optional

Delivery::

7-20 Days

Warranty Time::

1 Year/1000 Hours

Genset Dimension::

2800*1100*1500mm

Genset Weight::

2000kgs

Speed::

1500rpm/1800rpm

Model Number::

MB-200

Packaging Details:

Plastic wrapped on wooden bearers as consumer requirements. LCL, 20FT and 40FT are available.

Supply Ability:

200pcs/month

Highlight:

200kW Silent Diesel Generator Sets

YC6MK350L-D20 Silent Diesel Generator

YC6MK350L-D20 silent dg set

Product Description

Yuchai Diesel Generator Sets Description: 200kw rainproof electric generator
With YUCHAI engine YC6A275-D30
Less diesel consumption
Turbocharge aspiration
Reasonable and reliable emergency power generation
Warranty 12 months or 1000 hours warranty time

Manufacturer		Changsha Mingbang Intelligent Technology Co.Ltd
Model		MB-200
Prime Power		200KW/250KW
Power Factor		COSΦ=0.8(lagging)
Max. Output current		360A
Genset Weight		2000kg(Net)
Length x Width x Height (Engine) (mm)		280011001500
Voltage		400/230V
Frequency		50HZ
Yuchai Engine Specification
Manufacturer		Guangxi Yuchai Machinery Group Co., Ltd
Model		YC6MK350L-D20
Rated speed		1500rpm
Prime Power		235KW/293.75KVA
Standby Power		258.5KW/323.125KVA
Fuel Consumption		<=195g/KW.H
Lube oil capacity		52L
Bore (mm) x Stroke (mm)		123*145mm
Compression ratio		17.5:1
Displacement (litre)		9.84
Coolant capacity, L		/
Configuration		6 in line ,four-stroke, Turbocharged, Charge Air Cooled
Cooling		Liquid Cooled
Governor type		Electronic
Starting voltage		24 Volts DC
Filtration system		Air Filter/Fuel Filter/Oil Filter
Alternator Specification
Manufacturer		Changsha Mingbang Intelligent Technology Co.Ltd
Model		MBC27J
Voltage Regulator		AVR
Voltage adjust range		±1%
Rated Voltage/Frequency/Factor		400/230V, 50HZ, COSΦ 0.8(lagging) ,Three-phase Four-wire
Steady-state Frequency		5%
No-load Voltage Adjust Range		>=95%-105%
Insulation Class		H
IP Protection		22
Excitation Type		Blushless

Yuchai Silent Diesel Generator Sets YC6MK350L-D20 200KW/250KVA for sale 0

About MingBang Intelligent Technology

Mingbang is the professional manufacturer of power generator, light tower and air compressor in China. We provides a complete line of generators for commercial,industrial and residential application.works closely with all large power manufactures such as Cummins, Perkins, Deutz,Volvo and Chinese local brands SDEC,Yuchai,Jichai diesel generator sets,engines with Stamford,Marathom,Leroy-Somer,and MBKL manufactured alternators ,and so on. We specialize in providing a wide range of well known and trusted brands of diesel generators, supplying generators from 4kw to 2200kw at competitive prices.
Besides generators, we also product the refer product include lighting towers and air compressor. At the same time, we also provide the reference electrical products, include ATS, Synchronization system & switch gear.

Yuchai Silent Diesel Generator Sets YC6MK350L-D20 200KW/250KVA for sale 3

Silent Diesel Generator Set 200kW Domestic Diesel Generator Yuchai Copper Generator YC6MK350L-D20

Diesel generator power range from 4kw-2200kw
Engine brand :Doosan,weichai ,yuchai ,ricardo and so on .
Alternator brand :Stamford,Marathon,Lerory Somer and so on .
Control module:Smartgen,CoMap,Deepsea and so on

More details for diesel generator sets ,please contact us any time
