Yuchai Diesel Generator Sets With ATS for Charging Open Type Silent Type

Name: Yuchai Diesel Generator Sets With ATS for Charging Open Type Silent Type
Brand: Changsha Mingbang Intelligent Technology Co., Ltd.
SKU: YC6T780L-D20
Price: 591,700.00 USD
Availability: InStock

Brand Name:	Yuchai
Model Number:	YC6T780L-D20
MOQ:	1PC
Price:	Price:Negotiable
Payment Terms:	Western Union,T/T,D/P,L/C
Supply Ability:	200pcs/month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO 9001:14000,CE,EACC

Brand Name::

Yuchai Diesel Generator 400KW

Rated Voltage::

230V/400V

Engine Model::

Yuchai YC6T780L-D20

Rated Current::

900A

Frequency::

50Hz/60Hz

Alternator::

MBC5B

Control Panel::

Deepsea / Harsen / Smartgen

Certificate::

ISO 9001:14000,CE

ATS::

Optional

Delivery::

7-30 Days

Warranty Time::

1 Year

Genset Dimension::

3600×1550×1950mm

Genset Weight::

3800kgs

Speed::

1500rpm/1800rpm

Model Number::

MB-B500

Packaging Details:

Plastic wrapped on wooden bearers as consumer requirements. LCL, 20FT and 40FT are available.

Supply Ability:

200pcs/month

Highlight:

400KW Diesel Generators Sets

900A Diesel Generators Sets

900A portable diesel generator

Product Description

Yuchai diesel generator set specifications:

a) Diesel engine with all accessories, 3 filter, electric systems

b) Alternator

c) Steel structure

d) Fan and water tank cooling system

e) Flange connector

f) 12 / 24V starting motor and charge engine

g) Air cleaner, fuel cleaner, oil cleaner

h) On-board control panel

i) MCCB air conservation switch

j) 12 / 24V starting accumulator and battery line

k) Set shock absorber

l) High-efficient silencer

Manufacturer		Changsha Mingbang Intelligent Technology Co.Ltd
Model		MB-500
Prime Power		400KW/437.5KW
Power Factor		COSΦ=0.8(lagging)
Max. Output current		900A
Genset Weight		3800kg(Net)
Length x Width x Height (Engine) (mm)		3600×1550×1950
Voltage		400/230V
Frequency		50HZ
Yuchai Engine Specification
Manufacturer		Guangxi Yuchai Machinery Group Co., Ltd
Model		YC6TD840L-D20
Rated speed		1500rpm
Prime Power		520KW/650KVA
Standby Power		572KW/715KVA
Fuel Consumption		<=195g/KW.H
Lube oil capacity		52L
Bore (mm) x Stroke (mm)		152*180mm
Compression ratio		15:01
Displacement (litre)		16.35
Coolant capacity, L		/
Configuration		6 in line ,four-stroke, Turbocharged, Charge Air Cooled
Cooling		Liquid Cooled
Governor type		Electronic
Starting voltage		24 Volts DC
Filtration system		Air Filter/Fuel Filter/Oil Filter
Stamford Alternator Specification
Manufacturer		Changsha Mingbang Intelligent Technology Co.Ltd
Model		MBC5D
Voltage Regulator		AVR
Voltage adjust range		±1%
Rated Voltage/Frequency/Factor		400/230V, 50HZ, COSΦ 0.8(lagging) ,Three-phase Four-wire
Steady-state Frequency		5%
No-load Voltage Adjust Range		>=95%-105%
Insulation Class		H
IP Protection		22
Excitation Type		Blushless

Yuchai Diesel Generator Sets With ATS for Charging Open Type Silent Type 0

Diesel Generator Sets Diesel Generator For Home Portable Diesel Generator Small Diesel Generator With ATS

Yuchai Diesel Generator Sets With ATS for Charging Open Type Silent Type 3

<<<<<Changsha Mingbang Intelligent Technology Co., Ltd.>>>>>>>

1.Mingbang is devoted to the R&D and manufacturing of diesel generator sets since 2005

2. Mingbang new factory covers an area of 5042 square meters located in Jiang du industrial park of Yang zhou city.

3.Mingbang quality certified by ISO9001 & ISO14001 Management System to guarantee high quality products and service.

5.Mingbang maintaining long term strategic friendship cooperation with domestic and abroad famous manufactures of Cummins, Perkins, Doosan, SDEC, Mitsubishi(SME), Deutz, Wuxi Wandi, Leroysomer, Stamford, and Marathon etc.

6.We have so wide products ranges from 5kva to 3000kva for the diesel generator set; power from 25kva to 1500kva for gas generator set;

7.Soundproof/weather proof type, container type generator set; movable, vehicle type generator sets. Regarding to the electrical control systems, it covers Auto control panel, Synchronization panels, ATS etc.

8.Mingbang can also provide customized solution due to customer requirements upon our standard product supply in order to meet the demand of market. To focus on global market, create AOSIF as international brand, and constantly improve our quality level and maximize customer profitability is AOSIF unchangeable promise and eternal pursuit.

Our customers

More details for diesel generator sets ,please contact us any time

Your further inquiry will be welcome!!
