Yuchai 50Hz 60Hz 600KW 1080A Silent Diesel Generator Sets

Name: Yuchai 50Hz 60Hz 600KW 1080A Silent Diesel Generator Sets
Brand: Changsha Mingbang Intelligent Technology Co., Ltd.
SKU: YC6TD900-D31
Price: 591,700.00 USD
Availability: InStock

Brand Name:	Yuchai
Model Number:	YC6TD900-D31
MOQ:	1PC
Price:	Price:Negotiable
Payment Terms:	Western Union,T/T,D/P,L/C
Supply Ability:	200pcs/month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO 9001:14000,CE,EACC

Brand Name::

Yuchai Diesel Generator 600KW

Rated Voltage::

230V/400V

Engine Model::

Yuchai YC6TD900-D31

Rated Current::

1080A

Frequency::

50Hz/60Hz

Alternator::

MBC6A

Control Panel::

Deepsea / Harsen / Smartgen

Certificate::

ISO 9001:14000,CE

ATS::

Optional

Delivery::

7-30 Days

Warranty Time::

1 Year

Genset Dimension::

3800*1500*1950mm

Genset Weight::

8500kgs

Speed::

1500rpm/1800rpm

Model Number::

MB-B500

Packaging Details:

Plastic wrapped on wooden bearers as consumer requirements. LCL, 20FT and 40FT are available.

Supply Ability:

200pcs/month

Highlight:

1080A Silent Diesel Generator Sets

600KW Silent Diesel Generator Sets

600KW soundproof diesel generator

Product Description

Yuchai diesel generator control system:

a) Automatic alarm system: the unit has the acousto-optics alarm system and

arrestor for any situation as the start defeat, the water is over temperature, the oil

pulls down, over speed, over load and over current

b) Operation display:

i) Unit voltage, tri-phase load current and frequency display

ii) Water temperature, oil pressure display

iii) Fuel level, fuel temperature display

iv) Audible and visual alarm lamps and buzzers

Yuchai 50Hz 60Hz 600KW 1080A Silent Diesel Generator Sets 0

Manufacturer		Changsha Mingbang Intelligent Technology Co.Ltd
Model		MB-600
Prime Powder		600KW/750KW
Power Factor		COSΦ=0.8(lagging)
Max. Output current		1080A
Genset Weight		8500kg(Net)
Length x Width x Height (Engine) (mm)		380015001950
Voltage		400/230V
Frequency		50HZ
Yuchai Engine Specification
Manufacturer		Guangxi Yuchai Machinery Group Co., Ltd
Model		YC6TD900-D31
Rated speed		1500rpm
Prime Powder		605KW/756.25KVA
Standby Powder		665KW/831.25KVA
Fuel Consumption		<=215g/KW.H
Lube oil capacity		52L
Bore (mm) x Stroke (mm)		152*180mm
Compression ratio		14.5:01
Displacement (litre)		39:58
Coolant capacity, L		/
Configuration		6 in line ,four-stroke, Turbocharged, Charge Air Cooled
Cooling		Liquid Cooled
Governor type		Electronic
Starting voltage		24 Volts DC
Filtration system		Air Filter/Fuel Filter/Oil Filter
Mingbang Motor Specification
Manufacturer		Changsha Mingbang Intelligent Technology Co.Ltd
Model		MBC6A
Voltage Regulator		AVR
Voltage adjust range		±1%
Rated Voltage/Frequency/Factor		400/230V, 50HZ, COSΦ 0.8(lagging) ,Three-phase Four-wire
Steady-state Frequency		5%
No-load Voltage Adjust Range		>=95%-105%
Insulation Class		H
IP Protection		22
Excitation Type		Blushless

Yuchai 50Hz 60Hz 600KW 1080A Silent Diesel Generator Sets 1

4KW Super Silent Diesel Generator Sound Proof Type 50Hz 60Hz Diesel Generator Set Philippines With Good Quality

Yuchai 50Hz 60Hz 600KW 1080A Silent Diesel Generator Sets 4

<<<<<Changsha Mingbang Intelligent Technology Co., Ltd.>>>>>>>

1.Mingbang is devoted to the R&D and manufacturing of diesel generator sets since 2005

2. Mingbang new factory covers an area of 5042 square meters located in Jiang du industrial park of Yang zhou city.

3.Mingbang quality certified by ISO9001 & ISO14001 Management System to guarantee high quality products and service.

5.Mingbang maintaining long term strategic friendship cooperation with domestic and abroad famous manufactures of Cummins, Perkins, Doosan, SDEC, Mitsubishi(SME), Deutz, Wuxi Wandi, Leroysomer, Stamford, and Marathon etc.

6.We have so wide products ranges from 5kva to 3000kva for the diesel generator set; power from 25kva to 1500kva for gas generator set;

7.Soundproof/weather proof type, container type generator set; movable, vehicle type generator sets. Regarding to the electrical control systems, it covers Auto control panel, Synchronization panels, ATS etc.

8.Mingbang can also provide customized solution due to customer requirements upon our standard product supply in order to meet the demand of market. To focus on global market, create AOSIF as international brand, and constantly improve our quality level and maximize customer profitability is AOSIF unchangeable promise and eternal pursuit.

Our customers

More details for diesel generator sets ,please contact us any time

Your further inquiry will be welcome!!
