products details

Created with Pixso. Home Created with Pixso. Products Created with Pixso.
Three Phase AC Generator
Created with Pixso.

Yuchai diesel generator set 1000KVA Silent/open type

Yuchai diesel generator set 1000KVA Silent/open type

Yuchai diesel generator set 1000KVA Silent/open type

Brand Name: Yuchai
Model Number: YC6C1020-D31
MOQ: 1PC
Price: Price:Negotiable
Payment Terms: Western Union,T/T,D/P,L/C
Supply Ability: 200pcs/month
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
ISO 9001:14000,CE,EACC
Brand Name::
Yuchai Diesel Generator 800KW
Rated Voltage::
230V/400V
Engine Model::
Yuchai YC6C1020-D31
Rated Current::
1440A
Frequency::
50Hz/60Hz
Alternator::
MBC6C
Control Panel::
Deepsea / Harsen / Smartgen
Certificate::
ISO 9001:14000,GB
ATS::
Optional
Delivery::
7-30 Days
Warranty Time::
1 Year
Genset Dimension::
4600*1800*2500mm
Genset Weight::
7000kgs
Speed::
1500rpm/1800rpm
Model Number::
MB-B800
Packaging Details:
Plastic wrapped on wooden bearers . LCL, FCL
Supply Ability:
200pcs/month
Highlight:

275KVA Three Phase Diesel Generator

,

220KW Three Phase Diesel Generator

,

275KVA 3 phase diesel generator

Product Description

Yuchai diesel generator set specifications:

4-2200kw diesel generator with Yuchai engine

We produce and export 4-2200kw diesel generator sets. Diesel generator sets are widely used in field construction, high-rise buildings, schools, hospitals, industrial and mining enterprises, farms, villages and other places where electricity is needed.

Yuchai diesel generator set 1000KVA Silent/open type 0

Manufacturer Changsha Mingbang Intelligent Technology Co.Ltd
Model MB-800
Prime Power 800KW/1000KVA
Power Factor COSΦ=0.8(lagging)
Max. Output current 1440A
Genset Weight 7000kg(Net)
Length x Width x Height (Engine) (mm) 4600*1800*2500
Voltage 400/230V
Frequency 50HZ
Engine Specification
Manufacturer Guangxi Yuchai Machinery Group Co., Ltd
Model YC6C1020-D31
Rated speed 1500rpm
Prime Power 880KW/1100KVA
Standby Power 968KW/1210KVA
Fuel Consumption <=215g/KW.H
Lube oil capacity 52L
Bore (mm) x Stroke (mm) 150*180mm
Compression ratio 14.5:01
Displacement (litre) 39:58
Coolant capacity, L /
Configuration 6 in line ,four-stroke, Turbocharged, Charge Air Cooled
Cooling Liquid Cooled
Governor type Electronic
Starting voltage 24 Volts DC
Filtration system Air Filter/Fuel Filter/Oil Filter
Alternator Specification
Manufacturer Changsha Mingbang Intelligent Technology Co.Ltd
Model MBC6D
Voltage Regulator AVR
Voltage adjust range ±1%
Rated Voltage/Frequency/Factor 400/230V, 50HZ, COSΦ 0.8(lagging) ,Three-phase Four-wire
Steady-state Frequency 5%
No-load Voltage Adjust Range >=95%-105%
Insulation Class H
IP Protection 22
Excitation Type Blushless


Yuchai diesel generator set 1000KVA Silent/open type 1Yuchai diesel generator set 1000KVA Silent/open type 2Yuchai diesel generator set 1000KVA Silent/open type 3Yuchai diesel generator set 1000KVA Silent/open type 4Yuchai diesel generator set 1000KVA Silent/open type 5Yuchai diesel generator set 1000KVA Silent/open type 6Yuchai diesel generator set 1000KVA Silent/open type 7





Tags:

275KVA 3 phase diesel generator

200kw Three Phase AC Generator

220KW Three Phase Diesel Generator
