Yuchai Engine 250kva 1200KW diesel generator set genset

Name: Yuchai Engine 250kva 1200KW diesel generator set genset
Brand: Changsha Mingbang Intelligent Technology Co., Ltd.
SKU: YC12VC2070-D31
Price: 591,700.00 USD
Availability: InStock

Brand Name:	Yuchai
Model Number:	YC12VC2070-D31
MOQ:	1PC
Price:	Price:Negotiable
Payment Terms:	Western Union,T/T,D/P,L/C
Supply Ability:	200pcs/month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO 9001:14000,CE,EACC

Brand Name::

Yuchai Diesel Generator 1200KW

Rated Voltage::

230V/400V

Engine Model::

Yuchai YC12VC2070-D31

Rated Current::

2160A

Frequency::

50Hz/60Hz

Alternator::

MBC7B

Control Panel::

Deepsea / Harsen / Smartgen

Certificate::

ISO 9001:14000,CE

ATS::

Optional

Delivery::

7-30 Days

Warranty Time::

1 Year

Genset Dimension::

6500*2300*2600mm

Genset Weight::

13350kgs

Speed::

1500rpm/1800rpm

Model Number::

MB-B1200

Packaging Details:

Plastic wrapped on wooden bearers as consumer requirements. LCL, 20FT and 40FT are available.

Supply Ability:

200pcs/month

Highlight:

Yuchai Engine Air Cooled Diesel Generator

1200KW Air Cooled Diesel Generator

1200KW 250 kva Diesel Generator

Product Description

Yuchai YC12VC2070-D31 diesel generator sets features:

.Withi integrated crank case, postposition gear chamber and point-line gear -meshing patent technology,the engine has the advantage of low noise.

.Wet cylinder number liner structure facilitates maintenance and repair.

.P7100 fuel pump,'p'Configuration injector and honeywell turbocharger provide better combustion,lower fuel consumption.

.Yuchai sealing technology inpton and valve oil seal,improving luve oil consumption.

.The 42crmo high pressure forged steel crankshaft,shaft diameter and fillet high-frequency quenching,improve fatigue strength and abrasive resistance.

.Based on the European engine development requirments,the engine overhaul period more than 12000hours.

Yuchai Engine 250kva 1200KW diesel generator set genset 0

Manufacturer		Changsha Mingbang Intelligent Technology Co.Ltd
Model		MB-1200
Prime Powder		1200KW/1500KW
Power Factor		COSΦ=0.8(lagging)
Max. Output current		2160A
Genset Weight		13350kg(Net)
Length x Width x Height (Engine) (mm)		650023002600
Voltage		400/230V
Frequency		50HZ
Engine Specification
Manufacturer		Guangxi Yuchai Machinery Group Co., Ltd
Model		YC12VC2070-D31
Rated speed		1500rpm
Prime Powder		1380KW/1725KVA
Standby Powder		1520KW/1900KVA
Fuel Consumption		<=210g/KW.H
Lube oil capacity		280L
Bore (mm) x Stroke (mm)		200*210mm
Compression ratio		13.5:01
Displacement (litre)		79:17
Coolant capacity, L		/
Configuration		12 V type ,four-stroke, Turbocharged, Charge Air Cooled
Cooling		Liquid Cooled
Governor type		Electronic
Starting voltage		24 Volts DC
Filtration system		Air Filter/Fuel Filter/Oil Filter
Alternator Specification
Manufacturer		Changsha Mingbang Intelligent Technology Co.Ltd
Model		MBC7B
Voltage Regulator		AVR
Voltage adjust range		±1%
Rated Voltage/Frequency/Factor		400/230V, 50HZ, COSΦ 0.8(lagging) ,Three-phase Four-wire
Steady-state Frequency		5%
No-load Voltage Adjust Range		>=95%-105%
Insulation Class		H
IP Protection		22
Excitation Type		Blushless

Yuchai Engine 250kva 1200KW diesel generator set genset 1

Yuchai Engine 250kva 1200KW diesel generator set genset 2

About MingBang Intelligent Technology

Mingbang Intelligent Technology Co.,LTD was established in 2005,occupies an area of 5042 square meters,located in Yangzhou city,Jiangsu Province,which is the central part of manufacturing industry zone in Southeast China near Shanghai

Mingbang works closely with all large power manufactures such as Cummins, Perkins, Deutz,
Volvoand Chinese local brands SDEC,Yuchai,Jichai diesel generator sets,engines with
Stamford,Marathom,Leroy-Somer,and MBKL manufactured alternators ,and so on. Key diesel
generator stock ranges from 10KVA to 3000 KVA, classifying silent generator, open generator ,
container generator, mobile genset, and so on.
Whether you require support for an office, residential development ,industrial development or
shopping centre, hospital,railways,prison, hotal, airport ,bank data centre, Mingbang will
support you the most reliable and most cost-efficient generators and accessories.
Weclome to visit our factory!

Yuchai Engine 250kva 1200KW diesel generator set genset 4

Trailer Diesel Generator Emergency Power Soundproof Generator Durable High Power Diesel Generator

Direct injection internal combustion engine (diesel); Yuchai Engine Co., Ltd.
AC synchronous generator (single bearing); KC generator
Suitable for environment 40 ° C -50 ° C radiator water tank, belt drive cooling fan, fan safety shield;
Power output air switch, standard control screen; (HGM6110U supports eight languages worldwide)
unit steel common base (including: unit composite damping rubber pad);
Dry air filter, fuel filter, oil filter, starter motor, and self-charging generator;
Start the battery and battery start connection cable;
Industrial 90dB silencer and standard parts for connection
Molded case circuit breaker
Thick plastic fiMB packaging
Random data: original technical documents of diesel engines and generators, generator sets, test reports, etc.
