SDEC Engine 625kVA SDEC Diesel Generators Sets Gensets 500KW

Name: SDEC Engine 625kVA SDEC Diesel Generators Sets Gensets 500KW
Brand: Changsha Mingbang Intelligent Technology Co., Ltd.
SKU: SC25G690D2
Price: 591,700.00 USD
Availability: InStock

Brand Name:	SDEC SDEC
Model Number:	SC25G690D2
MOQ:	1PC
Price:	Price:Negotiable
Payment Terms:	Western Union,T/T,D/P,L/C
Supply Ability:	200pcs/month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO 9001:14000,CE,EACC

Brand Name::

SDEC Diesel Generator 500KW

Rated Voltage::

230V/400V

Engine Model::

SC25G690D2

Rated Current::

900A

Frequency::

50Hz/60Hz

Alternator::

MBC5D

Control Panel::

Deepsea / Harsen / Smartgen

Certificate::

ISO 9001:14000,CE

ATS::

Optional

Delivery::

7-30 Days

Warranty Time::

1 Year

Genset Dimension::

3550×1400×1900mm

Genset Weight::

3700kgs

Speed::

1500rpm/1800rpm

Model Number::

MB-S500

Packaging Details:

Plastic wrapped on wooden bearers as consumer requirements. LCL, 20FT and 40FT are available.

Supply Ability:

200pcs/month

Highlight:

625kVA SDEC Diesel Generators Sets

625kVA SDEC gensets

SDEC Engine Diesel Generators Sets

Product Description

SDEC SDEC SC25G690D2 diesel generator sets features:

a) Diesel engine with all accessories, 3 filter, electric systems

b) Alternator

c) Steel structure

d) Fan and water tank cooling system

e) Flange connector

f) 12 / 24V starting motor and charge engine

g) Air cleaner, fuel cleaner, oil cleaner

h) On-board control panel

i) MCCB air conservation switch

j) 12 / 24V starting accumulator and battery line

k) Set shock absorber

l) High-efficient silencer

Manufacturer		Changsha Mingbang Intelligent Technology Co.Ltd
Model		MB-S500
Prime Power		410KW/512.5KVA
Standby Power		460KW/575KVA
Power Factor		COSΦ=0.8(lagging)
Max. Output current		900 A
Genset Weight		3700KG
Length x Width x Height (Engine) (mm)		3550×1400×1900
Voltage		400/230V
Frequency		50HZ
Engine Specification
Manufacturer		SDEC
Model		SC25G690D2
Rated speed		1500rpm
Prime Power		460KW/575KVA
Standby Power		505KW/631.25KVA
Fuel Consumption		<=210g/KW.H
Lube oil capacity		57.4L
Bore (mm) x Stroke (mm)		135×150
Compression ratio		16.8:1
Displacement (litre)		25.8L
Coolant capacity, L		/
Configuration		12 V type ,four-stroke, Turbocharged, Charge Air Cooled
Cooling		Liquid Cooled
Governor type		Electronic
Starting voltage		24 Volts DC
Filtration system		Air Filter/Fuel Filter/Oil Filter
Alternator Specification
Manufacturer		Changsha Mingbang Intelligent Technology Co.Ltd
Model		MBC5D
Voltage Regulator		AVR
Voltage adjust range		±1%
Rated Voltage/Frequency/Factor		400/230V, 50HZ, COSΦ 0.8(lagging) ,Three-phase Four-wire
Steady-state Frequency		5%
No-load Voltage Adjust Range		>=95%-105%
Insulation Class		H
IP Protection		22
Excitation Type		Blushless

SDEC Engine 625kVA SDEC Diesel Generators Sets Gensets 500KW 0

Our factory

Our factory has CCEC, DCEC, VOLVO, PERKINS,MTU,Deutz, Daewoo, SDEC, Weichai,Jichai etc. World and Chinese famous engine for generators set. We have specialized in synchronous 100%copper wire alternator for more than 20 years. MB brand alternator has been expanded all over the world. The power range of our generator is from 6.5KW~2000KW.

Generator With Perkins/Cummins Engine 30kVA 60kVA 100kVA 120kVA 150kVA 200kVA 250kVA Top Quality Generator Factory

FAQ Of SDEC diesel generators prices

1.Which parameters you need to know?
a.We design the product according to your request, such as:
Power, Working Life, Water/Air-Cooler, Open Frame , Silent and Wheel
2.How to deal with broken machine?
a.We provide professional technical response to your question, we make
Sure the configuration, feature, optional item can work.
Maintenance Return your parts to us (Freight by yourself)
b. Enclose more parts when shipment
Parts Reply to you as quickly as possible

3. What do we warranty?
One year quality warranty.
Offer 24 hours service on telephone helpline. Whichever comes first.
a.During guarantee period, we provide free quick-wear parts for
problem caused by our quality of production or raw material.
b.After expiration, we provide spare parts maintenance for half price.
4.What about Guarantee?
a.Good reputation for reliable quality and reasonable price
b.Advanced production line by skilled workers
c.Two hours strictly testing of the machine before shipment
d.CE ISO BV

More details for diesel generator sets ,please contact us any time

Your further inquiry will be welcome!!
