Home Use 8KW 14.4KVA Air Cooled Diesel Generator sets with Yangdong engine

Name: Home Use 8KW 14.4KVA Air Cooled Diesel Generator sets with Yangdong engine
Brand: Changsha Mingbang Intelligent Technology Co., Ltd.
SKU: YD380D
Price: 3,000.00 USD
Availability: InStock

Brand Name:	Yangdong
Model Number:	YD380D
MOQ:	1PC
Price:	Price:Negotiable
Payment Terms:	Western Union,T/T,D/P,L/C
Supply Ability:	200pcs/month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO 9001:14000,CE,EACC

Brand Name::

Yangdong Small Diesel Generator 8KW

Rated Voltage::

230V/400V

Engine Model::

SC33W1150D2

Rated Current::

14.4A

Frequency::

50Hz/60Hz

Alternator::

MBC164B

Control Panel::

Deepsea / Harsen / Smartgen

Certificate::

ISO 9001:14000,CE

ATS::

Optional

Delivery::

7-30 Days

Warranty Time::

1 Year

Genset Dimension::

1900X730X1130mm

Genset Weight::

600kgs

Speed::

1500rpm/1800rpm

Model Number::

MB-YD8

Packaging Details:

Plastic wrapped on wooden bearers as consumer requirements. LCL, 20FT and 40FT are available.

Supply Ability:

200pcs/month

Highlight:

14.4KVA Air Cooled Diesel Generator

8KW Air Cooled Diesel Generator

14.4KVA home diesel generator

Product Description

Yangdong YD380D diesel generator sets features:

Genset specs:
8kw rainproof electric generator
With SDEC engine YD380D
Less diesel consumption
Turbocharge aspiration
Reasonable and reliable emergency power generation
Warranty 12 months or 1000 hours warranty time

Manufacturer		Jiangsu Mingbang Intelligent Technology Co.Ltd
Model		MB-YD8
Prime Power		8KW/10KVA
Standby Power		9KW/11.25KVA
Power Factor		COSΦ=0.8(lagging)
Max. Output current		14.4 A
Genset Weight		600 KG(NET)
Length x Width x Height (Engine) (mm)		1900X730X1130mm
Rated Voltage		400/230V
Frequency		50HZ
Engine Specification
Manufacturer		Yangdong
Model		YD380D
Rated speed		1500rpm
Prime Power		9KW/11.25KVA
Standby Power		10KW/12.5KVA
Fuel Consumption		<=260g/KW.H
Lube oil capacity		4.5 L
Bore (mm) x Stroke (mm)		85x90
Compression ratio		18:1
Displacement (litre)		1.357L
Coolant capacity, L		3.5 L
Configuration		3 in line ,four-stroke, Turbocharged, Charge Air Cooled
Cooling		Liquid Cooled
Governor type		Mechanical
Starting voltage		24 Volts DC
Filtration system		Air Filter,Fuel Filter,Oil Filter
Alternator Specification
Manufacturer		Jiangsu Mingbang Intelligent Technology Co.Ltd
Model		MBC164B
Voltage Regulator		AVR(Auto-voltage stabilization)
Voltage adjust range		±1%
Rated Voltage/Frequency/Factor		400/230V, 50HZ, COSΦ 0.8(lagging) ,Three-phase Four-wire
Steady-state Frequency		better than 5%
No-load Voltage Adjust Range		>=95%-105%
Insulation Class		H
IP Protection		23
Excitation Type		Single bearing, Brushless, Self-excited

Home Use 8KW 14.4KVA Air Cooled Diesel Generator sets with Yangdong engine 0

Our factory
Mingbang Co.,Ltd is one of the leading and largest world-wide producers and exporters for Diesel Generator (land diesel power generator&marine diesel generating set) and Gasoline Generator set from 1kva up to 2500kva. Transformed from a state owned enterprise and founded in 2005, Mingbang's Factory and generators assembling centers have more than two decades of experience in the design, research and manufacturing of diesel genset in strict compliance with ISO and CE standards. Up to being now, more than 20,000 sets of high quality generator set from mingbang have been working well in many fields including railways, oil fields, Schools, hospitals, banks, supermarkets, industries, tall buildings, sea ports and military bases etc.

Home Use 8KW 14.4KVA Air Cooled Diesel Generator sets with Yangdong engine 3

Home Use Air Cooled Single Phase Silent Type Portable Diesel Generator 220V 50HZ 1500/1800RPM 8KW/14.4KVA

More details for diesel generator sets ,please contact us any time

Your further inquiry will be welcome!!
