YND485D Engine 15kw Industrial Diesel Generators With ATS Yangdong diesel gensets

Name: YND485D Engine 15kw Industrial Diesel Generators With ATS Yangdong diesel gensets
Brand: Changsha Mingbang Intelligent Technology Co., Ltd.
SKU: YND485D
Price: 5,000.00 USD
Availability: InStock

Brand Name:	Yangdong
Model Number:	YND485D
MOQ:	1PC
Price:	Price:Negotiable
Payment Terms:	Western Union,T/T,D/P,L/C
Supply Ability:	200pcs/month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO 9001:14000,CE,EACC

Brand Name::

Yangdong Small Diesel Generator 15KW

Rated Voltage::

230V/400V

Engine Model::

YND485D

Rated Current::

27A

Frequency::

50Hz/60Hz

Alternator::

MBC164B

Control Panel::

Deepsea / Harsen / Smartgen

Certificate::

ISO 9001:14000,CE

ATS::

Optional

Delivery::

7-30 Days

Warranty Time::

1 Year

Genset Dimension::

2100x730x1130mm

Genset Weight::

750kgs

Speed::

1500rpm/1800rpm

Model Number::

MB-YD15

Packaging Details:

Plastic wrapped on wooden bearers as consumer requirements. LCL, 20FT and 40FT are available.

Supply Ability:

200pcs/month

Highlight:

15kw Industrial Diesel Generators

YND485D 15kw diesel generator

YND485D Industrial Diesel Generators

Product Description

Yangdong YND485D diesel generator sets features:

a) Diesel engine with all accessories, 3 filter, electric systems

b) Alternator

c) Steel structure

d) Fan and water tank cooling system

e) Flange connector

f) 12 / 24V starting motor and charge engine

g) Air cleaner, fuel cleaner, oil cleaner

h) On-board control panel

i) MCCB air conservation switch

j) 12 / 24V starting accumulator and battery line

k) Set shock absorber

l) High-efficient silencer

Manufacturer		Jiangsu Mingbang Intelligent Technology Co.Ltd
Model		MB-YD15
Prime Power		13KW/16.25KVA
Standby Power		15KW/18.75KVA
Power Factor		COSΦ=0.8(lagging)
Max. Output current		25A
Genset Weight		750 KG(NET)
Length x Width x Height (Engine) (mm)		2100x730x1130
Rated Voltage		400/230V
Frequency		50HZ
Engine Specification
Manufacturer		Yangdong
Model		YND485D
Rated speed		1500rpm
Prime Power		15KW/18.75KVA
Standby Power		17KW/21.25KVA
Fuel Consumption		<=247g/KW.H
Lube oil capacity		6 L
Bore (mm) x Stroke (mm)		85x95
Compression ratio		18:1
Displacement (litre)		2.156L
Coolant capacity, L		3.5 L
Configuration		4 in line ,four-stroke, Turbocharged, Charge Air Cooled
Cooling		Liquid Cooled
Governor type		Mechanical
Starting voltage		24 Volts DC
Filtration system		Air Filter,Fuel Filter,Oil Filter
Alternator Specification
Manufacturer		Jiangsu Mingbang Intelligent Technology Co.Ltd
Model		MBC184ES
Voltage Regulator		AVR(Auto-voltage stabilization)
Voltage adjust range		±1%
Rated Voltage/Frequency/Factor		400/230V, 50HZ, COSΦ 0.8(lagging) ,Three-phase Four-wire
Steady-state Frequency		better than 5%
No-load Voltage Adjust Range		>=95%-105%
Insulation Class		H
IP Protection		23
Excitation Type		Single bearing, Brushless, Self-excited

YND485D Engine 15kw Industrial Diesel Generators With ATS Yangdong diesel gensets 0

Our factory
Mingbang Co.,Ltd is the professional manufacturer of power generator, light tower and air compressor in China. We provides a complete line of generators for commercial,industrial and residential application.We specialize in providing a wide range of well known and trusted brands of diesel generators, supplying generators from 5kw to 2000kw at competitive prices.
Besides generators, we also product the refer product include lighting towers and air compressor. At the same time, we also provide the reference electrical products, include ATS, Synchronization system & switch gear.

Brushless AC Generator 12kw 21.6kVA Silent Soundproof Brushless Alternator Diesel Generator

Our Service

1. Ensure good quality, good package for transporation and deliver on time during the production phase;

2. Manging sea freight to customer's port of destination;

3. Be responsible for the after-sales service.

More details for diesel generator sets ,please contact us any time
