20KW Yangdong Diesel Standby Generator Set

Name: 20KW Yangdong Diesel Standby Generator Set
Brand: Changsha Mingbang Intelligent Technology Co., Ltd.
SKU: YSD490D
Price: 591,700.00 USD
Availability: InStock

Brand Name:	Yangdong
Model Number:	YSD490D
MOQ:	1PC
Price:	Price:Negotiable
Payment Terms:	Western Union,T/T,D/P,L/C
Supply Ability:	200pcs/month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO 9001:14000,CE,EACC

Brand Name::

Yangdong Small Diesel Generator 20KW

Rated Voltage::

230V/400V

Engine Model::

YSD490D

Rated Current::

36A

Frequency::

50Hz/60Hz

Alternator::

MBC184E

Control Panel::

Deepsea / Harsen / Smartgen

Certificate::

ISO 9001:14000,CE

ATS::

Optional

Delivery::

7-30 Days

Warranty Time::

1 Year

Genset Dimension::

2200x730x1140mm

Genset Weight::

780kgs

Speed::

1500rpm/1800rpm

Model Number::

MB-YD20

Packaging Details:

Plastic wrapped on wooden bearers as consumer requirements. LCL, 20FT and 40FT are available.

Supply Ability:

200pcs/month

Highlight:

20000W Diesel Standby Generator

YSD490D Engine Diesel Standby Generator

20000W dynamo diesel generators

Product Description

Yangdong YSD490D diesel generator sets features:

Rated frequency 50/60 HZ

Rated voltage 230/400V, 220/380V, according to customers

Power factor: 0.8(lag)

Super Silent type Noise level at 7m ≤65DB

Excitation Mode: (Brushless) Self-excitation and constant voltage (AVR)

Starting system: Electric start 12V/24V

Protection System: High water temperature protection, Engine oil alarm, Over load Protection

Over frequency protection, Emergency stop

Control System: Digital Control Panel; Meter Panel

Option: ATS,AMF,Trailer,Container

20KW Yangdong Diesel Standby Generator Set 0

Manufacturer		Jiangsu Mingbang Intelligent Technology Co.Ltd
Model		MB-YD20
Prime Powder		18KW/22.5KVA
Standby Powder		20KW/25KVA
Power Factor		COSΦ=0.8(lagging)
Max. Output current		28.8 A
Genset Weight		780 KG(NET)
Length x Width x Height (Engine) (mm)		2200x730x1140
Rated Voltage		400/230V
Frequency		50HZ
Engine Specification
Manufacturer		Yangdong
Model		YSD490D
Rated speed		1500rpm
Prime Powder		20KW/25KVA
Standby Powder		21KW/26.25KVA
Fuel Consumption		<=247.5g/KW.H
Lube oil capacity		6.5 L
Bore (mm) x Stroke (mm)		90x100
Compression ratio		18:1
Displacement (litre)		2.54L
Coolant capacity, L		/
Configuration		4 in line ,four-stroke, Turbocharged, Charge Air Cooled
Cooling		Liquid Cooled
Governor type		Mechanical
Starting voltage		24 Volts DC
Filtration system		Air Filter,Fuel Filter,Oil Filter
Alternator Specification
Manufacturer		Jiangsu Mingbang Intelligent Technology Co.Ltd
Model		MBC184E
Voltage Regulator		AVR(Auto-voltage stabilization)
Voltage adjust range		±1%
Rated Voltage/Frequency/Factor		400/230V, 50HZ, COSΦ 0.8(lagging) ,Three-phase Four-wire
Steady-state Frequency		better than 5%
No-load Voltage Adjust Range		>=95%-105%
Insulation Class		H
IP Protection		23
Excitation Type		Single bearing, Brushless, Self-excited

20KW Yangdong Diesel Standby Generator Set 1

Our factory
Mingbang Co.,Ltd is the professional manufacturer of power generator, light tower and air compressor in China. We provides a complete line of generators for commercial,industrial and residential application.We specialize in providing a wide range of well known and trusted brands of diesel generators, supplying generators from 5kw to 2000kw at competitive prices.
Besides generators, we also product the refer product include lighting towers and air compressor. At the same time, we also provide the reference electrical products, include ATS, Synchronization system & switch gear.

20KW Yangdong Diesel Standby Generator Set 3
Diesel Standby Generator Dynamo Diesel Generator Perkins Volvo MTU Cummins Exclusive Distributor

1a. Diesel engine

1b. Alternator

1c. Control panel

1d. The accessories, Wave pipe, Curved Pipe, Muffler, Accumulator, The connecting wires, Shock absorber spacer, Bellows, Documents and data and so on

Your further inquiry will be welcome!!
