Air Cooled Diesel Generator Set
Created with Pixso.

Y490D Engine 27A 20KW Air Cooled Diesel Generator

Y490D Engine 27A 20KW Air Cooled Diesel Generator

Brand Name: Yangdong
Model Number: Y490D
MOQ: 1PC
Price: Price:Negotiable
Payment Terms: Western Union, T/T, D/P, L/C
Supply Ability: 200pcs/month
Detail Information
Place of Origin:
China
Certification:
ISO 9001:14000,CE,EACC
Brand Name::
Yangdong Small Diesel Generator 20KW
Rated Voltage::
230V/400V
Engine Model::
Y490D
Rated Current::
27A
Frequency::
50Hz/60Hz
Alternator::
MBC184G
Control Panel::
Deepsea / Harsen / Smartgen
Certificate::
ISO 9001:14000,CE
ATS::
Optional
Delivery::
7-30 Days
Warranty Time::
1 Year
Genset Dimension::
2200x730x1140mm
Genset Weight::
780kgs
Speed::
1500rpm/1800rpm
Model Number::
MB-YD20
Packaging Details:
Plastic wrapped on wooden bearers as consumer requirements. LCL, 20FT and 40FT are available.
Supply Ability:
200pcs/month
Highlight:

Y490D Engine Air Cooled Diesel Generator

,

Y490D 20KW Diesel Generator

,

27A Air Cooled Diesel Generator

Product Description

Air Cooled Diesel Engine small diesel genset with perkins volvo engine and stamford motor with ATS factory price



Yangdong Y490D diesel generator sets features:



Diesel generator power range from 8kw-2000kw

Gas generator power range from 10kw-1000kw

Engine brand :Doosan,weichai ,yuchai ,ricardo and so on .

Alternator brand :Stamford,Marathon,Lerory Somer and so on .

Control module:Smartgen,CoMap,Deepsea and so on

Y490D Engine 27A 20KW Air Cooled Diesel Generator 0

Manufacturer Jiangsu Mingbang Intelligent Technology Co.Ltd
Model MB-YD20
Prime Powder 20KW/25KVA
Standby Powder 22KW/27.5KVA
Power Factor COSΦ=0.8(lagging)
Max. Output current 36A
Genset Weight 780 KG(NET)
Length x Width x Height (Engine) (mm) 2200x730x1140
Rated Voltage 400/230V
Frequency 50HZ
Engine Specification
Manufacturer Yangdong
Model Y490D
Rated speed 1500rpm
Prime Powder 22KW/27.5KVA
Standby Powder 24KW/30KVA
Fuel Consumption <=243g/KW.H
Lube oil capacity 8 L
Bore (mm) x Stroke (mm) 90x105
Compression ratio 18:1
Displacement (litre) 2.67L
Coolant capacity, L 5 L
Configuration 4 in line ,four-stroke, Turbocharged, Charge Air Cooled
Cooling Liquid Cooled
Governor type Mechanical
Starting voltage 24 Volts DC
Filtration system Air Filter,Fuel Filter,Oil Filter
Alternator Specification
Manufacturer Jiangsu Mingbang Intelligent Technology Co.Ltd
Model MBC184G
Voltage Regulator AVR(Auto-voltage stabilization)
Voltage adjust range ±1%
Rated Voltage/Frequency/Factor 400/230V, 50HZ, COSΦ 0.8(lagging) ,Three-phase Four-wire
Steady-state Frequency better than 5%
No-load Voltage Adjust Range >=95%-105%
Insulation Class H
IP Protection 23
Excitation Type Single bearing, Brushless, Self-excited


Y490D Engine 27A 20KW Air Cooled Diesel Generator 1Y490D Engine 27A 20KW Air Cooled Diesel Generator 2Y490D Engine 27A 20KW Air Cooled Diesel Generator 3

Our factory

Mingbang Co.,Ltd is one of the leading and largest world-wide producers and exporters for Diesel Generator (land diesel power generator&marine diesel generating set) and Gasoline Generator set from 1kva up to 2500kva. Transformed from a state owned enterprise and founded in 2005, Mingbang's Factory and generators assembling centers have more than two decades of experience in the design, research and manufacturing of diesel genset in strict compliance with ISO and CE standards. Up to being now, more than 20,000 sets of high quality generator set from mingbang have been working well in many fields including railways, oil fields, Schools, hospitals, banks, supermarkets, industries, tall buildings, sea ports and military bases etc.

Y490D Engine 27A 20KW Air Cooled Diesel Generator 4
Air Cooled Diesel Engine Small Diesel Genset With Perkins Volvo Engine And Stamford Motor With ATS Factory Price
Y490D Engine 27A 20KW Air Cooled Diesel Generator 5

FAQ:



Q1: Are you trading company or manufacturer ?
A: We are factory.
Q2: What is your MOQ of this item?
A: 1 set.
Q3: Is it all right to make customer's own brand name?
A: We can be your OEM manufacture with your authorization of brand.
Q4: What is your company's available production capacity?
A: 50 Sets per Month.
Q5: What is the lead time?
A: 2-7 working days after received the 30%T/T deposit.
Q6: What are your payment terms?
A: 30% TT as deposit,70% TT before Shipment.
Q7: Does your generator have global warranty?
A:Yes, most of our products such as Cummins,Perkins and so on enjoy the global warranty service.

And the alternator we use like Leroysomer, Stamford, marathon also enjoy the global warranty service.



More details for diesel generator sets ,please contact us any time
