WEICHAI Diesel Generator Set
Created with Pixso.

Diesel oil fuel Engine 400KW 500KVA Diesel Generators Sets with Weichai engine

Diesel oil fuel Engine 400KW 500KVA Diesel Generators Sets with Weichai engine

Brand Name: Weichai engine
Model Number: 6M26D447E200
MOQ: 1PC
Price: Price:Negotiable
Payment Terms: Western Union,T/T,D/P,L/C
Supply Ability: 200pcs/month
Detail Information
Place of Origin:
China
Certification:
ISO 9001:14000,CE,EACC
Brand Name::
Weichai Diesel Generator
Rated Voltage::
230V/400V
Frequency::
50Hz/60Hz
Control Panel::
Deepsea / Harsen / Smartgen
Certificate::
ISO 9001:14000,CE
ATS::
Optional
Delivery::
7-30 Days
Warranty Time::
1 Year
Speed::
1500rpm/1800rpm
Packaging Details:
Plastic wrapped on wooden bearers as consumer requirements. LCL, 20FT and 40FT are available.
Supply Ability:
200pcs/month
Highlight:

350KW Diesel Generator Sets

,

6M26D447E200 350KW Diesel Generator Sets

,

6M26D447E200 engine diesel generator

Product Description

Weichai 6M26D447E200 diesel generator sets features:


a) Diesel engine with all accessories, 3 filter, electric systems

b) Alternator

c) Steel structure

d) Fan and water tank cooling system

e) Flange connector

f) 12 / 24V starting motor and charge engine

g) Air cleaner, fuel cleaner, oil cleaner

h) On-board control panel

i) MCCB air conservation switch

j) 12 / 24V starting accumulator and battery line

k) Set shock absorber

l) High-efficient silencer

Diesel oil fuel Engine 400KW 500KVA Diesel Generators Sets with Weichai engine 0


Manufacturer Changsha Mingbang Intelligent Technology Co.Ltd
Model MB-400
Prime Power 400KW/500KVA
Power Factor COSΦ=0.8(lagging)
Max. Output current 720 A
Genset Weight 3900KG
Length x Width x Height (Engine) (mm) 3600mm×1550mm×2200mm
Voltage 400/230V
Frequency 50HZ
Engine Specification
Manufacturer Weichai Engine
Model 6M26D447E200
Rated speed 1500rpm
Prime Power 406KW/507.5KVA
Standby Power 447KW/558.75KVA
Fuel Consumption ≤202g/kw.h
Lube oil capacity 50L
Bore (mm) x Stroke (mm) 150×150mm
Displacement (litre) 25.8
Coolant capacity, L /
Configuration 6 in line ,four-stroke, Turbocharged, Charge Air Cooled
Cooling Liquid Cooled
Governor type Electronic
Starting voltage 24 Volts DC
Filtration system Air Filter/Fuel Filter/Oil Filter
Alternator Specification
Manufacturer Changsha Mingbang Intelligent Technology Co.Ltd
Model MBC5B
Voltage Regulator AVR
Voltage adjust range ±1%
Rated Voltage/Frequency/Factor 400/230V, 50HZ, COSΦ 0.8(lagging) ,Three-phase Four-wire
Steady-state Frequency 5%
No-load Voltage Adjust Range >=95%-105%
Insulation Class H
IP Protection 22
Excitation Type Blushless

Diesel oil fuel Engine 400KW 500KVA Diesel Generators Sets with Weichai engine 1Diesel oil fuel Engine 400KW 500KVA Diesel Generators Sets with Weichai engine 2

Rated power Engine Alternator Control panel
24kw~1500kw Cummins Stamford
Leroy somer
Marathon
Mecc alte
ABB
Chinese alternators
Deepsea
ComAp
Harsen
Smartgen
36kw~18+00kw Perkins
68kw~560kw Volvo
20kw~200kw Deutz
40kw-2200kw Yuchai
50kw-2200kw Weichai
540kw-1900kw Mitsubishi
50kw-800kw SDEC
650kw~2200kw Chinese engine


Application:
mainly apply to small tractors, farm vehicles, small generators, air compressors, inland shipping and power plant of agricultural processing (such as threshers, rice mills, milling machines, feed crusher, etc.).
Feature:
1. new design make diesel engine more beautiful;
2 .large capacity fuel tank to work longer;
3. sing uniaxial balance, so that the diesel engine is more balanced;
4. low fuel consumption, more economical diesel engine;
5. excellent starting performance, the starter is more convenient;
6. using an oil bath air filter, more adapted to the harsh working environment.








FAQ:

Q1: How is your Warranty?

Warranty: All Mingbang Intelligent Technology are warranted in accordance with our warranty terms

for a period of 12 months from date of dispatch or 1,200 running hours from date of commissioning whichever comes earlier.

Q2: Any advantages about your company?
-- Fast delivery time
-- Good design and high quality
-- Good service after sale
-- High quality with good price help you get more benefit and beat your competitors

Q3: Can you supply OEM service?
Yes, we can offer OEM service

Q4: How about the service after sale?
We have agents spread all over the world, our service network spanning more than 50 countries so we can ensure fast and good service for our clients. We are recruiting agents, welcome you to be our friend and get a win-win cooperation .
