Low Noise 30kw 400V Water Cooled Diesel Generator For Charging

Name: Low Noise 30kw 400V Water Cooled Diesel Generator For Charging
Brand: Changsha Mingbang Intelligent Technology Co., Ltd.
SKU: WP2.3D33E200
Price: 591,700.00 USD
Availability: InStock

Brand Name:	Weichai engine
Model Number:	WP2.3D33E200
MOQ:	1PC
Price:	Price:Negotiable
Payment Terms:	Western Union,T/T,D/P,L/C
Supply Ability:	200pcs/month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO 9001:14000,CE,EACC

Brand Name::

Weichai Open Diesel Generator 30KW

Rated Voltage::

230V/400V

Engine Model::

WP2.3D33E200

Rated Current::

54A

Frequency::

50Hz/60Hz

Alternator::

MBC22A

Control Panel::

Deepsea / Harsen / Smartgen

Certificate::

ISO 9001:14000,CE

ATS::

Optional

Delivery::

7-30 Days

Warranty Time::

1 Year

Genset Dimension::

1650*680*1250mm

Genset Weight::

650kgs

Speed::

1500rpm/1800rpm

Model Number::

MB-30

Packaging Details:

Plastic wrapped on wooden bearers as consumer requirements. LCL, 20FT and 40FT are available.

Supply Ability:

200pcs/month

Highlight:

400V Air Cooled Diesel Generator

30000w Air Cooled Diesel Generator

Air Cooled Diesel Generator For Charging

Product Description

Diesel Fueled Generators Air Cooled Diesel Engine MTU Deutz Cummins Diesel Generator Sets 30kw 5kw 50kw Small Power

Weichai WP2.3D33E200 diesel generator sets features:

(1) .Full control panel with power indicator light and oil light.
(2). Emergency shutdown for low oil pressure and high water temperature.
(3). Large fuel tank ensure continuous running.
(4). Low noise & vibration.
(5). Compact structure.
(6). Reliable performance.
(7). Easy for installation and maintenance.

Manufacturer		Changsha Mingbang Intelligent Technology Co.Ltd
Model		MB-30
Prime Power		30KW/37.5KVA
Power Factor		COSΦ=0.8(lagging)
Max. Output current		54 A
Genset Weight		680KG
Length x Width x Height (Engine) (mm)		16506801250mm
Voltage		400/230V
Frequency		50HZ
Engine Specification
Manufacturer		Weichai Engine
Model		WP2.3D33E200
Rated speed		1800rpm
Prime Power		30KW/37.5KVA
Standby Power		33KW/41.25KVA
Fuel Consumption		≤210g/kw.h
Lube oil capacity		10L
Bore (mm) x Stroke (mm)		90*100mm
Displacement (litre)
Coolant capacity, L		/
Configuration		4 in line ,four-stroke, Turbocharged, Charge Air Cooled
Cooling		Liquid Cooled
Governor type		Electronic
Starting voltage		24 Volts DC
Filtration system		Air Filter/Fuel Filter/Oil Filter
Alternator Specification
Manufacturer		Changsha Mingbang Intelligent Technology Co.Ltd
Model		MBC22A
Voltage Regulator		AVR
Voltage adjust range		±1%
Rated Voltage/Frequency/Factor		400/230V, 50HZ, COSΦ 0.8(lagging) ,Three-phase Four-wire
Steady-state Frequency		5%
No-load Voltage Adjust Range		>=95%-105%
Insulation Class		H
IP Protection		22
Excitation Type		Blushless

Low Noise 30kw 400V Water Cooled Diesel Generator For Charging 0

Our factory

Our factory has CCEC, DCEC, VOLVO, PERKINS,MTU,Deutz, Daewoo, SDEC, Weichai,Jichai etc. World and Chinese famous engine for generators set. We have specialized in synchronous 100%copper wire alternator for more than 20 years. MB brand alternator has been expanded all over the world. The power range of our generator is from 6.5KW~2000KW.

Low Noise 30kw 400V Water Cooled Diesel Generator For Charging 3

Diesel Fueled Generators Air Cooled Diesel Engine MTU Deutz Cummins Diesel Generator Sets 30kw 5kw 50kw Small Power

Q1: How is your Package & Payment & Delivery Date & Warranty?

A.1) Package: Plastic fiMB (free of charge) or wooden case (add USD200 for wooden)

A.2) Payment: by 30% T/T as deposit, 70% balance should be paid 10 days before shipment. Or 100% L/C at sight.

A.3) Delivery: 7-25 days after we get the down payment.

A.4) Warranty: Guarantee for one year or 1000 running hours (whichever come first shall apply) from installed date. During the guarantee period. Such as Cummins or Perkins generators. They are international brands and the after-sale service is worldwide. You can contact your country's after-sale or contact us for repairment. When replacing spare parts, please kindly take some pictures to describe the problems. We will solve it ASAP.

More details for diesel generator sets ,please contact us any time

Your further inquiry will be welcome!!
