LKD450 Engine Open type Diesel Generator set 400kw 500KVA

Name: LKD450 Engine Open type Diesel Generator set 400kw 500KVA
Brand: Changsha Mingbang Intelligent Technology Co., Ltd.
SKU: LKD450
Price: 3,000.00 USD
Availability: InStock

Brand Name:	Likaduo engine
Model Number:	LKD450
MOQ:	1 PC
Price:	Price:Negotiable
Payment Terms:	Western Union,T/T,D/P,L/C
Supply Ability:	200pcs/month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO 9001:14000,CE,EACC

Frequency:

50/60HZ

Speed:

1500/1800rpm

Rated Voltage:

400/230V

Product Name:

Diesel Genertor Set

Engine Brand:

Likaduo

Controller:

Smartgen/Deepsea/Comap

Engine Type:

LKD450

Packaging Details:

Plastic wrapped on wooden bearers as consumer requirements. LCL, 20FT and 40FT are available.

Supply Ability:

200pcs/month

Highlight:

Open Air Cooled Diesel Generator

500KVA Air Cooled Diesel Generator

1800rpm Engine Diesel Generator

Product Description

LKD450 Engine Open Diesel Generator 400kw 500KVA

Brand Name::	Likaduo Open Diesel Generator 400KW	Rated Voltage::	400V/230V
Engine Model::	LKD450	Rated Current::	720A
Frequency::	50Hz/60Hz	Alternator::	MBV5B
Control Panel::	Deepsea / Harsen / Smartgen	Certificate::	ISO 9001:14000,CE
ATS::	Optional	Delivery::	7-30 Days
Warranty Time::	1 Year	Genset Dimension::	3450×1400×1900mm
Genset Weight::	3200kgs	Speed::	1500rpm/1800rpm
Model Number::	MB-400
High Light:	400kw Open Diesel Generator, LKD450 Open Diesel Generator

Product Description

Weichai LKD450 diesel generator sets features:

(1) .Full control panel with power indicator light and oil light.
(2).Emergency shutdown for low oil pressure and high water temperature.
(3).Large fuel tank ensure continuous running.
(4).Low noise & vibration.
(5).Compact structure.
(6).Reliable performance.
(7).Easy for installation and maintenance.

Painting materials
rust removing in pickling tank(10minutes)------unoil(30mins)-----rinsing(3mins)----wathsetting(10mins)----rinsing(5mins)-----parkerising(20mins)----rinsing----blow dry-----stoving----pylons----spray paint(adopt static flame paint)-----Oven(170degree/20mins)-----draw a charge---inserting coil.

Manufacturer		Changsha Mingbang Intelligent Technology Co.Ltd
Model		MB-400
Prime Power		400KW/500KVA
Power Factor		COSΦ=0.8(lagging)
Max. Output current		720A
Genset Weight		3200KG
Length x Width x Height (Engine) (mm)		3450×1400×1900mm
Voltage		400/230V
Frequency		50HZ
Engine Specification
Manufacturer		Likaduo Engine
Model		LKD450
Rated speed		1500rpm
Prime Power		450KW
Standby Power		504KW
Fuel Consumption		≤239g/kw.h
Lube oil capacity		50L
Bore (mm) x Stroke (mm)		126×155mm
Displacement (litre)		14.9
Coolant capacity, L		/
Configuration		12 cylinder V-type, four stroke, water air cooling
Cooling		Liquid Cooled
Governor type		Electronic
Starting voltage		24 Volts DC
Filtration system		Air Filter/Fuel Filter/Oil Filter
Alternator Specification
Manufacturer		Changsha Mingbang Intelligent Technology Co.Ltd
Model		MBC5B
Voltage Regulator		AVR
Voltage adjust range		±1%
Rated Voltage/Frequency/Factor		400/230V, 50HZ, COSΦ 0.8(lagging) ,Three-phase Four-wire
Steady-state Frequency		5%
No-load Voltage Adjust Range		>=95%-105%
Insulation Class		H
IP Protection		22
Excitation Type		Blushless

Rated power	Engine	Alternator	Control panel
24kw~1500kw	Cummins	Stamford Leroy somer Marathon Mecc alte ABB Chinese alternators	Deepsea ComAp Harsen Smartgen
36kw~18+00kw	Perkins
68kw~560kw	Volvo
20kw~200kw	Deutz
40kw-2200kw	Yuchai
50kw-2200kw	Weichai
540kw-1900kw	Mitsubishi
50kw-800kw	SDEC
650kw~2200kw	Chinese engine

LKD450 Engine Open type Diesel Generator set 400kw 500KVA 0

Our factory

Mingbang Power Perkins Diesel Generating Set, power ranging from 45kVa up to 2250kVa. Perkins is the world's top engine brand, for more than 80 years, UK Perkins has been the world's leading supplier of diesel and gas engines in the 4 - 1800 kW market. Perkins key strength is its ability to tailor engines precisely to meet customers' requirements, which is why its engine solutions are trusted by more than 1,000 leading manufacturers in the industrial, construction, agricultural, materials handling and electrical power generation markets.

Our factory has CCEC, DCEC, VOLVO, PERKINS,MTU,Deutz, Daewoo, SDEC, Weichai,Jichai etc. World and Chinese famous engine for generators set. We have specialized in synchronous 100%copper wire alternator for more than 20 years. MB brand alternator has been expanded all over the world. The power range of our generator is from 6.5KW~2000KW.
