Weichai 12M26D748E200 Engine Open Type Diesel Generator Set 600kw 750KVA

Name: Weichai 12M26D748E200 Engine Open Type Diesel Generator Set 600kw 750KVA
Brand: Changsha Mingbang Intelligent Technology Co., Ltd.
SKU: 12M26D748E200
Price: 591,700.00 USD
Availability: InStock

Brand Name:	Weichai engine
Model Number:	12M26D748E200
MOQ:	1 PC
Price:	Price:Negotiable
Payment Terms:	Western Union,T/T,D/P,L/C
Supply Ability:	200pcs/month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO 9001:14000,CE,EACC

Frequency:

50/60HZ

Speed:

1500/1800rpm

Rated Voltage:

400/230V

Product Name:

Diesel Genertor

Engine:

Weichai

Controller:

Smartgen/Deepsea/Comap

Engine Type:

12M26D748E200

Packaging Details:

Plastic wrapped on wooden bearers as consumer requirements. LCL, 20FT and 40FT are available.

Supply Ability:

200pcs/month

Highlight:

Open type Diesel Generator set

750KVA Diesel Generator set

12M26D748E200 Diesel Generator set

Product Description

12M26D748E200 Engine Open Diesel Generator 600kw 750KVA

Brand Name::	Weichai Open Diesel Generator 600KW	Rated Voltage::	400V/230V
Engine Model::	12M26D748E200	Rated Current::	1080A
Frequency::	50Hz/60Hz	Alternator::	MBV6A
Control Panel::	Deepsea / Harsen / Smartgen	Certificate::	ISO 9001:14000,CE
ATS::	Optional	Delivery::	7-30 Days
Warranty Time::	1 Year	Genset Dimension::	3700×1650×2060mm
Genset Weight::	4200kgs	Speed::	1500rpm/1800rpm
Model Number::	MB-600
High Light:	600kw Open Diesel Generator, 12M26D748E200 Open Diesel Generator

Product Description

Weichai 12M26D748E200 diesel generator sets features:

(1) .Full control panel with power indicator light and oil light.
(2).Emergency shutdown for low oil pressure and high water temperature.
(3).Large fuel tank ensure continuous running.
(4).Low noise & vibration.
(5).Compact structure.
(6).Reliable performance.
(7).Easy for installation and maintenance.

Painting materials
rust removing in pickling tank(10minutes)------unoil(30mins)-----rinsing(3mins)----wathsetting(10mins)----rinsing(5mins)-----parkerising(20mins)----rinsing----blow dry-----stoving----pylons----spray paint(adopt static flame paint)-----Oven(170degree/20mins)-----draw a charge---inserting coil.

Manufacturer		Changsha Mingbang Intelligent Technology Co.Ltd
Model		MB-600
Prime Power		600KW/750KVA
Power Factor		COSΦ=0.8(lagging)
Max. Output current		1080A
Genset Weight		4200KG
Length x Width x Height (Engine) (mm)		3700×1650×2060mm
Voltage		400/230V
Frequency		50HZ
Engine Specification
Manufacturer		Weichai Engine
Model		12M26D748E200
Rated speed		1500rpm
Prime Power		600KW
Standby Power		748KW
Fuel Consumption		≤196g/kw.h
Lube oil capacity		50L
Bore (mm) x Stroke (mm)		150×150mm
Displacement (litre)		14:5:1
Coolant capacity, L		38.7L
Configuration		12cylinder V-type, four stroke, water air cooling
Cooling		Liquid Cooled
Governor type		Electronic
Starting voltage		24 Volts DC
Filtration system		Air Filter/Fuel Filter/Oil Filter
Alternator Specification
Manufacturer		Changsha Mingbang Intelligent Technology Co.Ltd
Model		MBV6A
Voltage Regulator		AVR
Voltage adjust range		±1%
Rated Voltage/Frequency/Factor		400/230V, 50HZ, COSΦ 0.8(lagging) ,Three-phase Four-wire
Steady-state Frequency		5%
No-load Voltage Adjust Range		>=95%-105%
Insulation Class		H
IP Protection		22
Excitation Type		Blushless

Rated power	Engine	Alternator	Control panel
24kw~1500kw	Cummins	Stamford Leroy somer Marathon Mecc alte ABB Chinese alternators	Deepsea ComAp Harsen Smartgen
36kw~18+00kw	Perkins
68kw~560kw	Volvo
20kw~200kw	Deutz
40kw-2200kw	Yuchai
50kw-2200kw	Weichai
540kw-1900kw	Mitsubishi
50kw-800kw	SDEC
650kw~2200kw	Chinese engine

Weichai 12M26D748E200 Engine Open Type Diesel Generator Set 600kw 750KVA 0

Our factory

Mingbang Power Weichai Diesel Generating Set, power ranging from 45kVa up to 2250kVa. Weichai is the world's top engine brand, for more than 80 years, Weichai has been the world's leading supplier of diesel and gas engines in the 4 - 1800 kW market. Weichai key strength is its ability to tailor engines precisely to meet customers' requirements, which is why its engine solutions are trusted by more than 1,000 leading manufacturers in the industrial, construction, agricultural, materials handling and electrical power generation markets.

Our factory has CCEC, DCEC, VOLVO, PERKINS,MTU,Deutz, Daewoo, SDEC, Weichai,Jichai etc. World and Chinese famous engine for generators set. We have specialized in synchronous 100%copper wire alternator for more than 20 years. MB brand alternator has been expanded all over the world. The power range of our generator is from 20KW~2000KW.
